Monitor Audio C2S, į lubas montuojama garso kolonėlė

This small Tier 2 in-ceiling loudspeaker is a two-way model featuring an RST II mid-bass driver and C-CAM tweeter. It has a cut out dimension of 171 mm and revolutionary patented Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable and strong installation and fitting.

This small Tier 2 in-ceiling loudspeaker is designed to deliver pristine, engaging acoustics where high-performance sound is a key requirement. It is a two-way model featuring an RST II mid-bass driver and C-CAM tweeter. The performance benefit of having both within a single design means greatly improved clarity, wider dispersion into the listening environment, and clear lifelike high-fidelity sound – of the quality you’d expect from any Monitor Audio passive box loudspeaker. It has a cut-out dimension of 171 mm and uses the patented Quik-Link speaker cable connecter, which revolutionises the ease and speed of speaker installation. Tri-Grip has also been evolved for simple, reliable and strong fitment.

Optional square grille can be used with this model.

Key Features
Ideal for installations where pristine acoustic performance is required.
Two-way design
1 x 1" (25 mm) C-CAM tweeter with UD Waveguide II for lifelike sound
1 x 5" (127 mm) RST II mid-bass driver for pristine mid-range and full bass
Patented Quik-Link speaker cable connector for quicker installation (UK patent application no. 2216966.8)
Tri-Grip II for easy and secure fitment

System Format
2–Way
Channels
1
Frequency Response, Installed (-6dB)
40 Hz – 30 kHz​
Nominal Impedance
8 ohm
Minimum Impedance (20Hz to 20kHz)
6.8 Ohm @ 150 Hz
Sensitivity (2.83Vrms@1m, Installed)
84 dB
Maximum Peak SPL* (single speaker @ 1m Z-Weighted)
111 dB
Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)
65 W
Recommended Amplifier Power (RMS into 8 OHM, Music Signal)
35 – 130 W
Drive Unit Complement
1 x 5" (127 mm) RST II mid-bass driver
1 x 1 (25 mm) C-CAM tweeter
Crossover Frequency
LF/HF: 2.5 kHz
Mounting Depth
99 mm (37/8")
Cut-Out Hole Diameter
171 mm (63/4")
External Dimensions (Including Grille (H x W x D))
201 x 201 x 103​ mm (715/16 x 715/16 x 44/16")
Weight (each)
1.5 kg (3 lb 5 oz)
Pre-Construction Bracket
CS-B
Cabinet Finish
Matte black & Orange​ & Bronze
Sold As
Single Unit
Corner Switch
On/Off
HF Switch
- /0/ +
