TANNOY CANTERBURY GR-OW, grindinė garso kolonėlė

Legendinis 15 colių „Dual“ buvo plačiai patobulintas „Gold Reference“ serijai, o daugelis patobulinimų yra „trikle-down“ technologija iš TANNOY pavyzdinio „Kingdom Royal“ plėtros projekto. Žemo dažnio GR tvarkyklės sekcija turi naują pluoštu praturtintą popieriaus masės kūginę medžiagą, kad būtų galima toliau tobulinti kūgio mechanines charakteristikas. Kūgis baigiamas dvigubu impregnuoto audinio rulonu, kad būtų pagerintos slopinimo savybės. „Canterbury GR“ HF įrenginys žymi reikšmingą šuolį į priekį technologijos ir našumo srityje, nes yra nauja aliuminio-magnio lydinio suspaudimo diafragma, kuri buvo termiškai apdorota, kad dar labiau pagerintų mechaninį vientisumą esant HF apkrovoms. Naudojant naujas „Mylar“ erdvines medžiagas užtikrinamas geresnis slopinimas ir aušinimas, todėl visame HF diapazone užtikrinamas išskirtinis aiškumas ir artikuliacija. „Gold Reference Dual“, galintis klausytis didelio garsumo be nuovargio, suteikia TANNOY Canterbury garsiakalbiui dar daugiau natūralumo ir ryškumo.

• 2 way floorstanding loudspeaker for large sized rooms
• Dual Concentric driver technology provides class-leading coherence and point-source imaging
• 15" highly efficient driver with 96 dB/Watt sensitivity and 600 Watt peak power handling deliver breath-taking dynamics and realism
• PepperPot WaveGuide powered by Tannoy Alnico magnet system enhances the point source symmetrical dispersion properties
• Aluminium-magnesium alloy diaphragm and Mylar surround compression driver delivers exceptional clarity and articulation throughout the high frequency range
• Handcrafted oiled walnut veneered cabinet with hand-selected burr walnut inlays provides a unique and timeless piece of furniture
• capacitors, low loss laminated core inductors and thick film resistors delivering a more natural and cohesive sound
• bi-wireable binding posts to improve signal transmission and integrity
• Fifth binding post provides grounding to reduce radio frequency interference and improve midrange clarity
• High density birch ply cabinet provides extreme rigidity to control low frequency performance
• Variable Distributed Port system allows low frequency output to be tuned to suit any room dimensions
• Extensive bracing incorporating DMT (Differential Materials Technology) to couple drivers to cabinets
• Precision machined gold anodised aluminium metal trims complement the aesthetic of the real wood cabinet
• Specially formulated Prestige wood wax provided to keep cabinet in pristine condition
• Tannoy - around 100 years of British sound heritage and innovation

• Nominal impedance: 8 Ohms
• Minimum Impedance: 5 Ohms
• Frequency Response: 28 Hz - 27 kHz (-6 dB)
• Dispersion: 90 degrees conical
• Recommended amplifier power: 20 - 300 Watts
• Continuous power handling: 150 Watts RMS
• Peak power handling: 600 watt
• Sensitivity: 96 dB (2.83 volt @ 1 m)
• Frequency: 1.1kHz
• Type: Bi-wired, hard wired passive, low loss, Time compensated. 2nd order low pass. 2nd order high pass.
• Adjustment:
• +/-3 dB over 1.1 kHz to 27 kHz shelving
• 2 dB to -6 dB per octave over 5 kHz to 27 kHz slope
• Dual Concentric™ high frequency: 52 mm (2”) aluminium/magnesium alloy dome with round wire voice coil.
• Dual Concentric™ low frequency: 380 mm (15”) with paper pulp cone and twin roll impregnated fabric surround.52 mm (2”) round wire voice coil.
• Enclosure type: Dual variable distributed ported
• Volume: 235 l
• Dimensions: 1100 x 680 x 480mm
• Finish: High density birch ply, walnut veneered, with solid walnut trim, 25 mm (1”) thick front baffle.
• Internally cross braced and heavily damped.
