Audio Technica

Audio Technica AT33EV, turntable head

€499.00 EUR

Audio Technica AT33EV, turntable head is backordered and will ship as soon as it is back in stock.

Home delivery from €4.99

Venipak courier within 1-2 working days.

Collect in store €0

Armaturininkai str. 1, Kaunas
Working hours: IV 9:00-18:00

The new half-inch standard mount .3 x .7 millimeter elliptical AT33EV turntable head features a tapered duralumin console. The dual moving coil cartridge design maximizes channel separation and extends the frequency range for outstanding sound quality.

  • Frequency response 15 - 50,000 Hz
  • Channel separation 30 dB (1 kHz)
  • Vertical tracking angle 23°
  • Vertical tracking force 1.8-2.2g (standard 2.0g)

The new half-inch standard mount .3 x .7 mil elliptical AT33EV cartridge features a tapered duralumin cantilever. Dual Moving Coil cartridge design increases channel separation and extends the frequency response range delivering extraordinary audio quality. Internally constructed with neodymium magnet for enhanced magnetic energy and PCOCC wire for pure audio transmission.

SPECIFICATIONS

Cartridge & Stylus
Frequency Response 15 - 50,000Hz
Channel Separation 30dB (1kHz)
Vertical Tracking Angle 23°
Vertical Tracking Force 1.8 to 2.2 g (standard 2.0 g)
Stylus Construction Nude Square Shank
Recommended Load Impedance More than 100Ω (when head amp connected)
Coil Impedance 10Ω (1kHz)
DC Resistance 10Ω
Coil Inductance 22µH (1kHz)
Output Voltage 0.3mV (1kHz and 3.54cm/sec.)
Output Channel Balance 0.5dB (1kHz)
Stylus Shape Elliptical
Cantilever Duralumin
Static Compliance 40×10-6cm/dyne
Dynamic Compliance 10×10-6cm/dyne (100Hz)
Mounting 1/2" Centers
Dimensions H16×W16.6×D26.5mm
Accessories Included Non-magnetic screwdriver × 1, Washer × 2, Protector × 1, Cartridge installation screws 13 mm × 2 and 19 mm × 2, Nut × 2, Brush × 1, PCOCC lead set × 1
Body Material Aluminium/Synthetic Resin
Stylus Curvature Radius 0.3 x 0.7 mil
Terminal Pins Brass
Type Dual Moving Coil
Weight 6.9g


INSTRUCTIONS

User Manual (EN).
