Hertz

Hertz ES 200.5 car subwoofer

€90.00 EUR

Home delivery from €4.99

Venipak courier within 1-2 working days.

Collect in store €0

Armaturininkai str. 1, Kaunas
Working hours: IV 9:00-18:00

Compact car subwoofer from Hertz.

  • Power: 600 W
  • Sensitivity: 88.5 dB.
  • Frequency band: 30 ÷ 400 Hz.
  • V-CONE® technology

The Hertz Energy.5 ES 200.5 subwoofer offers a dynamic bass and is capable of outstanding SPL never achieved in this category of the market.
The introduction of the V-cone® technology had a big impact in the efficiency of the ES.5 subwoofers, also improving cone stiffness and reducing the weight of the moving assembly, allowing a higher strength voice coil for a higher peak power handling.
The implementation of the surround and spider geometry, as well as the selection of the materials used, contributed to achieving unmatched mechanical and thus acoustical linearity.
This, combined with a drastic reduction of the Vas, provides the ability to achieve high undistorted SPL output in even small enclosures.
The Hertz Energy.5 subwoofers are the perfect choice for solid, powerful bass in perfect harmony with improved vehicle integration.

1. V-cone® technology with water-repellent paper membrane, for reduced
moving assembly mass and increased sensitivity.
2. Wide-wave spider profile, for high mechanical resistance against impulsive
stress; its resin-bonded fiber ensures consistent electro-acoustic
parameters in time.
3. High density foam surround, for extreme mechanical and acoustical linearity,
even under high excursion.
4. Copper voice coil wound on aluminum former, combined with the spider
support cooling system and bottom plate vent holes, for outstanding thermal
capacity in power peaks.
5. Silver plated silicone shielded lead wires ending with tin-plated, high
current terminals for high resistance against mechanical stress and low
contact resistance.
6. High magnetic permeability plates and large magnet, ensuring a constant
and even magnetic flux, for perfect low frequency control.
7. Butyl rubber gasket and magnet protective cover, provide ideal coupling to
the mounting surface, damping basket resonances.


Technologies

  • V-CONE®

    The exponential profile gets very close to the perfect one, providing exceptional dispersion.

  • VERIFIED BY KLIPPEL

    The Klippel quality control system is our guarantee to always produce a product entirely in compliance with the most challenging international standards.



SPECIFICATIONS

Size mm (in.) 200 (8)
Power Handling - Peak W 600
Power Handling - Continuous W 200
Impedance Ω 4
Frequency response Hz 30 ÷ 400
Sensitivity dB SPL 88.5
Voice coil Ø mm (in.) 50 (2)
Xmax mm 9
X-Mech mm (in.) 13 (0.51)
Re Ω 2.9
Fs Hz 40
February l 10.5
Qts 0.5
Qes 0.53
Qms 10.57
Spl dB 88.5

INSTRUCTIONS

User Manual (EN).
