Jamo

Jamo JDA-500, DSP audio amplifier 100V

€999.00 EUR

Jamo JDA-500, DSP audio amplifier 100V is backordered and will ship as soon as it is back in stock.

▪️ Turite klausimų dėl šios prekės❓Galime pakonsultuoti telefonu +370 683 90000, arba mūsų salone Armatūrininkų g. 1, Kaunas.
📩 Taip pat galite siųsti mums užklausą į kurią atsakysime per 24 val.

Home delivery from €4.99

Venipak courier within 1-2 working days.

Collect in store €0

Armaturininkai str. 1, Kaunas
Working hours: IV 9:00-18:00

The JDA-500 offers the legendary Jamo standard power and performance packed into a highly ergonomic design.

  • Power: 4 x 125W.
  • Class G/H amplifier.
  • 4 x Phoenix connectors.
  • 4 x RCA connectors.

DESIGN

The Jamo JDA-500 offers legendary Jamo power and performance in a sleek, high-tech, 1 rack unit solution. The JDA-500 offers 500W of class G/H power, for clean, dynamic power in any type of installation.

From small residential systems to massive commercial installations, the JDA-500 is designed for maximum installation flexibility - offering low impedance and 70V/100V compatibility for distributed line applications.

TECHNOLOGY

The JDA-500 boasts fully matrixed 4x4 I/O with fully balanced Phoenix and unbalanced RCA inputs, as well as Phoenix speaker outputs capable of connecting up to 12-gauge wire. The myriad I/O, impedance, and acoustic settings are fully matrixed and customizable through the web-based, easy to use, streamlined DSP menu. In addition to password protected channel assignments, gain settings, EQ, and limiting, the DSP provides presets for almost every Jamo speaker on the market - optimizing acoustic performance and power handling for these products with a single click. Accessing the DSP wirelessly with a tablet, smartphone, or computer is also quick and easy when the JDA-500 is plugged into the network's wireless router.

SPECIFICATIONS

Signal to Noise -100dB Below Rated Output
Rack Unit 1RU
Outputs 4 x Phoenix Speaker Level (up to 12 AWG wire), 4 x RCA Line Level (Throughs)
Dimensions 44mm x 483mm x 363mm(1.73" x 19.02" x 14.29")
Amplifier Power Output 500W Total System Power4 x 125W Per Channel
Subwoofer Dimensions 6.82 kg (15 lbs)
Input Sensitivity 750mV Balanced, 0dBU
THD <1% @ Rated Output
Input Impedance Balanced 40k
Inputs Balanced: 4 x Phoenix Line Level (up to 12 AWG wire), Unbalanced: 4 x RCA Line Level
Speaker Enclosure Front Face: ABS PlasticCase: Machine Formed Steel
Amplifier Type High Efficiency Class G/H
Mounting Options Removable 1RU Rack Ears, Removable Rubber Feet

User manual / User manual.
