Monitor Audio IA750-4, home theater amplifier
Monitor Audio IA750-4, home theater amplifier - Ask you before buying whether we have this item in a warehouse if we do not have to be ordered and arrive within 2-21 days.
▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.
Free delivery in Lithuania from € 100
Free delivery in Lithuania from € 100
In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.
Pick up the goods in the store for € 0
Pick up the goods in the store for € 0
Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00
Monitor Audio IA750-4, home theater amplifier
- INFORMACIJA
- DESCRIPTION
- TECHNICAL DATA
- DOCUMENTS
The A750-4 delivers an incredible four channels of 750W of power and is the perfect amplifier for the most demanding large home theater setups.
- Power: 4 x 750 W
- Class D amplifier ensures high performance.
- Fully customizable DSP amplifier with online configurator.
In a larger installation where pure power is required, the Monitor Audio IA750-4 is the ideal choice. A 2U full width high-power amplifier, it features full DSP matrix configuration and is simple to install and use. But power is its trump card: four channels of 750 W each deliver the most impressive home theater sound imaginable. It's capable of getting the very best out of any system and is the perfect partner for Monitor Audio's THX Ultra certified Cinergy home theater system.
SPECIFICATIONS
Channels
4
Output Power @ 2 Ohms
4 x 750W SE
Output Power @ 4 Ohm
4 x 750W SE, 2 x 1500W BTL
Output Power @ 8 Ohm
2 x 400W SE, 2 x 1500W BTL
Output Power @ 70V
2 x 1200W BTL
Output Power @ 100V
2 x 1500W BTL
Maximum Total Output Power, all channels driven
3000 W
Power Consumption
700 W
Thermal Output
2400 BTU
Polarity (Default)
Non-inverting
Dimensions
88 x 440 x 329 mm (3 6/16 x 17 5/16 x 12 15/16 ”)
Output Voltage
80Vp / 160Vpp (SE unloaded), 160Vp / 320Vpp (BTL unloaded)
Signal to Noise Ratio
>108dB (A-weighted, 20Hz – 20kHz, 8 Ohm load)
THD+N (typical).
<0.05% (20 Hz – 20 kHz, 8 Ohm load, 3db below rated power)
Frequency Response
+0/-0.25dB 20Hz – 20kHz (8 Ohm load, 3dB below rated power
Protection Circuits
Short circuit -, DC, Undervoltage -, Temperature - and Overload protection
Power Supply
Switch mode power supply with Power Factor Correction (PFC) and standby converter
Operating Voltage/Frequency
Universal Mains, 100 V - 240 V, 50 Hz - 60 Hz
Standby Consumption
<0.5W
Accessories
Rack mount kit (pre-installed)
Power Ratings
1% THD @ 120Vac and 230Vac
Cabinet Finish
Black Anodized
