SPECIFICATIONS
DSP Modes (Presets)
Speech/Flat
Cartridge Type
Electret Condenser (16 mm)
Polar Pattern
Unidirectional (Cardioid)
Bit Depth
16-bit/24-bit
Sampling Rate
48 kHz
Frequency Response
20 Hz is 20,000 Hz
Adjustable Gain Range
0 to +36 dB
Sensitivity
-40 dBFS/Pa at 1 kHz[1] [2}
Maximum SPL
130 dB SPL [2]
Headphone Output
3.5mm (1/8″)
Power Requirements
Powered through USB connector
Mute Switch Attenuation
Yes
Mounting Stand
Included
Stand Adapter
1/4 inch 20 thread (standard tri-pod mount)
Housing
PC/ABS
Even Weight
Without Mounting Stand |
0.09kg(3.17oz.) |
With Mounting Stand |
0.16kg(5.64oz.) |
Dimensions
66 x 67 x 65 mm
H x W x D
Dimensions with Stand
89 x 142 x 97 mm
H x W x D
Cable
1 m USB-A cable/1 m USB-C cable
[1] 1 Pa=94 dB SPL
[2] At Minimum Gain, Flat Mode
![Polar pattern graph](https://s3.us-east-2.amazonaws.com/shure-pubs-staging/graphics/f_561bc637-da12-4153-9bc6-37da12d153e0-en-US.png)
Polar Pattern
![Frequency response chart](https://s3.us-east-2.amazonaws.com/shure-pubs-staging/graphics/f_7e136061-3341-4e55-9360-613341ce5534-en-US.png)
IN PACKAGING
- 1 - AMV5-DS Desktop Stand
- 1 - AMV-USB Micro-B-to-USB-A Cable (1m)
- 1 - 95C38076 Micro-B-to-USB-C Cable (1m)
