Alpine HDZ-110, car subwoofer
- INFORMACIJA
- DESCRIPTION
- TECHNICAL DATA
- DOCUMENTS
Alpine Introduces All-New Alpine Status Sound System: Alpine developed the Alpine Status using the same engineering and design concepts used in the third-generation ultra-high-resolution AlpineF#1Status system to achieve high-resolution sound. at a more affordable price. In addition, the Alpine Status system is extremely flexible: all components can be purchased and used separately.
- Recommended amplifier power: 200W.
- Frequency band: 25Hz – 300Hz.
- Sensitivity: 84dB SPL (2.83 V x2 @ 1 m).
- Resistance: 2 ohms + 2 ohms.
Superior Sound Performance
Alpine Introduces the all-new Alpine Status sound system: using the same engineering and design concepts drawn from the third generation, Ultra High-Resolution AlpineF#1Status system, Alpine created “ Alpine Status ” to achieve High-Resolution Sound at a more approachable and accessible price point. The Alpine Status system is also extremely flexible: all components can be purchased and used in a "stand-alone" configuration.
The massive, 28cm HDZ-110 Alpine Status subwoofer houses a powerful ferrite magnet to ensure efficient power delivery and features an impressive 400W RMS / 1200W Peak Power Handling. A Carbon Composite cone with double-gathered surround minimizes distortion to reproduce clean, accurate bass even at loud volumes. The HDZ-110 gets very close to the AlpineF#1Status subwoofer's look and feel, using a very similar construction and motor assembly, as well as identical build-materials for the highest sound quality.
Hi-Res Audio Made Accessible
The Alpine Status system features many technologies, components and materials of the AlpineF#1Status system to achieve ultra high-precision music reproduction - at an affordable price tag. It is designed to play music tracks at 192kHz / 24bit format, which are widely accessible in many online stores and streaming platforms. High-Res Audio playback of 192kHz / 24bit allows Alpine Status to create a heightened listening experience in the vehicle that emulates the feeling of an intimate recording studio session.
28cm High-Performance Subwoofer
Drawing from AlpineF#1Status subwoofer development lessons, we created the HDZ-110 Alpine Status 28cm subwoofer. It comes very close to its bigger brother's performance, build quality and design. It features a dual 2Ohm configuration, an ultra-strong baked carbon cone, double-gathered surround, heavy-gauge screw-terminals and a huge ferrite magnet.
Carbon Fiber Cone
The HDZ-110 Alpine Status subwoofer features a backed carbon composite cone to achieve a fully unified timbre identity with the Alpine Status speakers – resulting in excellent harmonics. Carbon is very lightweight and stiff, resulting in high dynamics and low distortion. Backed carbon composite technology is also used in race-car monocoques for its light weight and high strength.
Alpine Status Full System
Alpine Status features many components that are optimized in both power and performance as a complete system to play at their intended high-resolution spec for excellent, audiophile sound quality. However, each component can be purchased independently for custom system building.
Premium Build-Quality
Yet another trickle-down technology from the AlpineF#1Status subwoofer: the double-gathered edge allows maximum cone excursion with excellent cone control and stability. This reduces sound distortion caused by cone wobble at higher volume levels.
Dual 2 Ohm Configuration
This subwoofer features dual 2 Ohm voice coils, allowing it to be driven by 2 mono amps. You can also create a 4 Ohm configuration by creating a series connection and use the HDA-V90 's subwoofer channel. Refer to the owner's manual linked below to see all connection configurations.
Studio Recording Spec
Alpine Status achieves 192kHz/24Bit playback, which is 6.5 times the amount of digital audio data in a standard CD or digital streaming service and exceeds the standard High-Resolution spec of 96kHz/24Bit found in most aftermarket sound solutions. This allows Alpine Status to capture and accurately reproduce details like the breath of the artist or a musician's subtle interaction with an instrument. This capability not only reproduces music to the artist's original intention, but emulates the experience of a studio recording in the vehicle.
SPECIFICATIONS
Features
- AlpineF#1Status speaker trickle-down technology
- Maximum Peak Power Handling: 1200 Watts
- Maximum RMS Power Handling: 400 Watts
- Aluminum die-cast frame
- Backed carbon fiber cone
- Double-gathered edge
- Heavy-gauge screw-type cable terminals
- High-performance ferrite magnet
Specifications
- Impedance: 2 Ohm + 2 Ohm
- Woofer diameter: 279mm
- Cut-out diameter: 251mm
- Mounting depth: 196mm
- Sensitivity 84dB SPL (2.83 V x2 @ 1 m)
- Frequency Response: 25Hz - 300Hz
- Recommended amplification: up to 200W / 2 Ohm RMS per channel
Thiele & Small Parameters:
- Re: 6.03 Ohms
- fps: 30.8 Hz
- Mms: 387.143 g
- Rms: 12.368 kg/s
- Cms: 0.069 mm/N
- BI: 29.491 N/A
- Qms: 6,048
- Qes: 0.519
- Qts: 0.478
- February: 48.9213 l
- SD: 706.86 cm2
