Naim

Naim CI-NAP 101, power amplifier

€1,499.00 EUR

▪️ Do you have questions about this product?❓We can consult by phone +370 683 90000 or come to our salon Armatūrinininkų St. 1, Kaunas.

Free delivery in Lithuania from € 100

In Lithuania, Venipak courier delivery is available via 1-2 business days.
Delivery outside Lithuania within 4-10 business days.

Pick up the goods in the store for € 0

Armatūrinininkų St. 1, Kaunas
Working hours: Thursday 9:00-18:00

The CI-NAP 101 is a high performance single power amplifier compatible with 70V/100V line array speakers. It is designed to be extremely quiet and compact, making it easy to install discreetly almost anywhere. The amplifier is perfect for powering subwoofers or integrated hi-fi speakers that require a lot of power while ensuring exceptional sound quality. In addition, it can be used in conjunction with an audio-visual processor to install custom devices for the highest performance.

 

Power And Sound Quality

The CI-NAP 101, part of the CI Series range, has been designed and manufactured by Naim engineers to complement Focal integrated loudspeakers and create an outstanding sound installation. It can operate with an output load of 2 ohms, making it the perfect choice for amplifying the 1000 IWLCR Utopia loudspeakers and two 1000 IWSUB Utopia subwoofers from Focal. This discreet solution is the epitome of excellence.

Key Features

- Stereo RCA inputs and stereo RCA outputs for series connection.

- Two Euroblock outputs for easy parallel connections between speakers.

- High impedance 70V/100V line amplification with a selectable high-pass filter.

- Level control.

- Input signal detection with automatic power-down after 20 minutes.

- Universal 100V to 240V mains power supply

Focal & Naim App

With the Focal & Naim app, you can take control of your home hi-fi system and access millions of tracks with ease. You can control various product settings and features all from one convenient app. Plus, you can enjoy instant playback via your connected Naim devices, no matter which room they're in. This app is the perfect tool for music lovers who want to have all their music options at their fingertips.

The application is available from Apple Store and Google Play Store.

Number of channels 1
Power low
impedance
8Ω 500W
4Ω 800W
2Ω Stable
Power high
impedance
100V 240W
70V 150W
Input connections Analogue – Stereo RCA - Combined to mono - (47 kΩ)
Output connections
Line Stereo RCA
Low Impedance Euroblock
70V Euroblock
100V Euroblock
Total Harmonic Distortion (THD+N@1 kHz) <0.008%
Gain 29dB
Signal-to-noise ratio 110dB (A - Weighted)
Frequency response
(-3dB)
Low impedance 3Hz - 70kHz
High impedance 50Hz/120Hz - 25kHz
Operating power supply 100V to 240V +/-10%, 50/60Hz
Wired automation 12V in/out
Rack height 1U
Dimensions (H x W x D) 13/4x173/8x113/4" (4.45x44x30cm)
Weight 19.62lbs (8.9kg)
Nominal power consumption 100W
Power consumption in standby mode 0.5W
Operating temperature 5°C to 35°C
Storage temperature -20°C to 60°C

User manual (EN)
