Observation NTSC 1/3 inch Sony AHD, front camera

Name: Observation NTSC 1/3 inch Sony AHD, front camera
Brand: RVC
SKU: Observation NTSC 1/3 inch Sony AHD
Price: 235.20 EUR
Availability: InStock

€235.20 EUR

Observation NTSC 1/3 inch Sony AHD, front camera is backordered and will ship as soon as it is back in stock.

Home delivery from €4.99

Venipak courier within 1-2 working days.

Collect in store €0

Armaturininkai str. 1, Kaunas
Working hours: IV 9:00-18:00

INFORMACIJA
TECHNICAL DATA

INFORMACIJA

Front camera that can work in mirror mode. The camera can also be used as a rear camera.

Sensor: 1/3 inch Sony AHD.
Resolution: 1280x960.
Resistance standard IP 69K.
Cable length: 7.7 m.
Video RCA connector.

TECHNICAL DATA

Product features

Mini observation camera
Sensor type 1/3 inch Sony AHD sensor with narrow angle
Picture format NTSC color
Resolution 1280x960 Pixel
Angle horizontal 65°, diagonal 80°
Unmirrored picture (fixed)
Protection class IP69K
Suitable for permanent operation
Housing and camera color black
Total cable length about 7.70 m
Video-connector RCA male connector
System connector camera 4pin BM
Diameter camera connector 5mm

Specifications

Operating voltage	5V~15V
Current consumption	80mA
Weight incl. cable about	225 g
Operating temperature range	-20°C to +65°C
Dimensions camera only	28 x 19 x 19mm (W x H x H)
Dimensions camera with housing	54 x 47 x 28mm (W x H x H)
