Rotel

Rotel A12MKII, integrated audio amplifier (various colors)

€1,258.95 EUR

Rotel A12MKII, integrated audio amplifier (various colors) - Black is backordered and will ship as soon as it is back in stock.

▪️ Turite klausimų dėl šios prekės❓Galime pakonsultuoti telefonu +370 683 90000 arba atvykite į mūsų saloną Armatūrininkų g. 1, Kaunas.

Home delivery from €4.99

Venipak courier within 1-2 working days.

Collect in store €0

Armaturininkai str. 1, Kaunas
Working hours: IV 9:00-18:00

The A12MKII integrated amplifier stands out with its slim, elegant design profile, designed and tailored for music fans.

  • Power: 2 x 60W.
  • Class AB amplifier.
  • DAC: Texas Instruments premium 32-bit/384kHz.
  • Moving Magnet Phono input for turntables.

The A12MKII Integrated Amplifier stands well above its slim, sleek design profile designed and engineered for music lovers.

Powered by Rotel's oversized in-house manufactured toroidal transformer the A12MKII delivers 60 Watts of clean, dynamic Class AB output power into 8 ohms.

A Moving Magnet Phono Stage, 4 RCA analog, 4 digital, PC-USB and high quality wireless aptX TM Bluetooth input ensures connection to your favorite sources.

The premium 32-bit Texas Instruments DAC extracts genuine and accurate details of the music with optimized circuits preserving the integrity of the audio stream.

Slim and powerful, the A12MKII delivers on Rotel's iconic brand heritage.

SPECIFICATIONS


Engineered with care.

Rotel A12MKII, integrated audio amplifier (various colors)

DIMENSIONS (W × H × D) 430 × 93 × 345mm
17" × 3.6" × 13.5" FRONT PANEL HEIGHT 80mm (3.15") POWER REQUIREMENTS 120V, 60Hz POWER CONSUMPTION 230W STANDBY POWER CONSUMPTION <0.5W NET WEIGHT 8.76kg (19.31lbs.) BTU RATING (4Ω, 1/8th power) 632 BTU/h

Rotel A12MKII, integruotas garso stiprintuvas (įvairių spalvų)

MAXIMUM POWER OUTPUT 120W/Ch (4Ω) CONTINUOUS POWER OUTPUT 60W/Ch (8Ω) TOTAL HARMONIC DISTORTION (THD) <0.018% FREQUENCY RESPONSE Line Level Inputs: 10Hz - 100kHz, 0±0.5dB Digital Inputs: 10Hz - 90kHz, 0±2dB Phono Input: 20Hz - 20kHz, 0±0.5dB S/N WHEEL (IHF "A" Weighted)
 Line Level Inputs: 100dB Digital Inputs: 103dB Phono Input: 90dB
INTERMODULATION DISTORTION (60Hz:7kHz, 4:1) <0.03% DAMPING FACTOR 220 INPUT SENSITIVITY Line Level Inputs: 230mV Digital Inputs: 0dBfs Phono Input (MM): 3.4mV INPUT IMPEDANCE Line Level Inputs: 24kΩ Digital Inputs: 75Ω Phono Input (MM): 47kΩ INPUT OVERLOAD Line Level Inputs: 4V Phono Input: 50mV PREOUT LEVEL 1.2V OUTPUT IMPEDANCE 470Ω TONE CONTROLS ±10dB at 100Hz / 10kHz DIGITAL INPUT SPDIF LPCM (Up to 24-bit/192kHz) PC-USB USB Audio Class 1 (up to 24-bit/96kHz) USB Audio Class 2 (up to 32-bit/384kHz)* *Driver installation required Roon Tested

INSTRUCTIONS

User Manual (EN).

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
Rotel A12MKII, integruotas garso stiprintuvas (įvairių spalvų)- sidabrinė
Rotel

Rotel A12MKII, integrated audio amplifier (various colors)

€1,258.95 EUR

The A12MKII integrated amplifier stands out with its slim, elegant design profile, designed and tailored for music fans.

DESCRIPTION

The A12MKII Integrated Amplifier stands well above its slim, sleek design profile designed and engineered for music lovers.

Powered by Rotel's oversized in-house manufactured toroidal transformer the A12MKII delivers 60 Watts of clean, dynamic Class AB output power into 8 ohms.

A Moving Magnet Phono Stage, 4 RCA analog, 4 digital, PC-USB and high quality wireless aptX TM Bluetooth input ensures connection to your favorite sources.

The premium 32-bit Texas Instruments DAC extracts genuine and accurate details of the music with optimized circuits preserving the integrity of the audio stream.

Slim and powerful, the A12MKII delivers on Rotel's iconic brand heritage.

TECHNICAL DATA

SPECIFICATIONS


Engineered with care.

Rotel A12MKII, integrated audio amplifier (various colors)

DIMENSIONS (W × H × D)
430 × 93 × 345mm
17" × 3.6" × 13.5"
FRONT PANEL HEIGHT
80mm (3.15")
POWER REQUIREMENTS
120V, 60Hz
POWER CONSUMPTION
230W
STANDBY POWER CONSUMPTION
<0.5W
NET WEIGHT
8.76kg (19.31lbs.)
BTU RATING (4Ω, 1/8th power)
632 BTU/h

Rotel A12MKII, integruotas garso stiprintuvas (įvairių spalvų)

MAXIMUM POWER OUTPUT
120W/Ch (4Ω)
CONTINUOUS POWER OUTPUT
60W/Ch (8Ω)
TOTAL HARMONIC DISTORTION (THD)
<0.018%
FREQUENCY RESPONSE
Line Level Inputs: 10Hz - 100kHz, 0±0.5dB
Digital Inputs: 10Hz - 90kHz, 0±2dB
Phono Input: 20Hz - 20kHz, 0±0.5dB
S/N WHEEL (IHF "A" Weighted)
Line Level Inputs: 100dB
Digital Inputs: 103dB
Phono Input: 90dB

INTERMODULATION DISTORTION (60Hz:7kHz, 4:1)
<0.03%
DAMPING FACTOR
220
INPUT SENSITIVITY
Line Level Inputs: 230mV
Digital Inputs: 0dBfs
Phono Input (MM): 3.4mV
INPUT IMPEDANCE
Line Level Inputs: 24kΩ
Digital Inputs: 75Ω
Phono Input (MM): 47kΩ
INPUT OVERLOAD
Line Level Inputs: 4V
Phono Input: 50mV
PREOUT LEVEL
1.2V
OUTPUT IMPEDANCE
470Ω
TONE CONTROLS
±10dB at 100Hz / 10kHz
DIGITAL INPUT
SPDIF LPCM (Up to 24-bit/192kHz)
PC-USB
USB Audio Class 1 (up to 24-bit/96kHz)
USB Audio Class 2 (up to 32-bit/384kHz)*
*Driver installation required
Roon Tested

DOCUMENTS

INSTRUCTIONS

User Manual (EN).
